Facsimile Machine Trainer

Circuit boards feature plexiglass covers, which have openings for access to all test points for instrument readings

Each trainer is designed to instruct service technicians in the operation, theory, servicing, problem diagnosis and repair

• A unique fault insertion system is built into the trainer for student instruction purposes and includes 20 faults
• The system features a schematic block diagram silk-screened onto an integral fault board that utilizes LEDs to indicate the nature and location of the fault
• Touching an electronic switch with a special teaching probe activates the fault
• Activated faults are visualized by use of the corresponding LED illuminates on the fault board
• The LEDs can also be switched off thereby not allowing the student to know where the fault is
