FAN VIBRATION MODULE

A module that attaches to a machinery diagnostics base unit to simulate a fan rotor system under load, enabling students to observe vibrational effects at different speeds and load forces. Vibrations are generated as a function of torque, resistance, and blade count. An adjustable magnet induces vibrations in the fan blades. Learn about FAN VIBRATION MODULE for educational labs for optimal educational outcomes..

• Fan rotor: Sheet steel; 3, 5 and 7 blade variants; Ø204 mm
• Zero blade disc also provided
• Mounting disc: Ø220 mm, aluminium
• Adjustable magnet distance/force to induce blade vibrations
