Faraday’s Effect Experiment Setup with He Ne Laser for Physics Lab Experiments

Faraday Effect Experimental Setup is designed to study the Faraday Effect and measure the Verdet Constant of a glass rod. The setup provides the required optical and electrical components for studying the rotation of the plane of polarization in a magnetic field.

Physics Lab Experiments Setup from Atico Exports.

Experiment :

• To Study the Faraday Effect
• To Measure the Verdet Constant of a Glass Rod

Setup Contains :

He-Ne Laser :

• Laser Tube with Power Supply
• Housed in a Thick Powder-Coated Aluminum Box
• Wavelength: 6328 Å
• Light Color: Red
• Polarization: Random
• Output Power: 2 mW

Optical Bench :

• Length: 1.5 m
• Stainless Steel Rods
• Two Slow-Motion Riders
• Two Fixed Riders
• Two Stands

Solenoid :

• Solenoid with Sample Glass Rod
• Designed for Measurement of Verdet Constant

Power Supply :

• Power Supply for Solenoid

Ammeter :

• Provided for Current Measurement

Analyzer and Polarizer :

• Supplied with Rod

Supporting Stands :

• Suitable Stands for Coil and Laser

Photo Cell :

• Supplied with Multimeter

Technical Specifications :

Usage / Application :

• Laboratory

Material :

• Stainless Steel
