Fiber Communication Experiment Kit – Basic Model

This fiber optics experiment system is designed to introduce the fundamental principles of optical fiber communication and transmission. It provides a cost-effective platform for performing essential fiber optics experiments, including optical coupling, transmission loss measurement, fiber interference, and fiber optic sensing applications. Manufactured by Atico Export India.

Experiments :

• Study the Fundamental Principles of Optical Fiber Communication.
• Perform Optical Fiber and Light Source Coupling Experiments.
• Measure the Numerical Aperture (NA) of Multimode Optical Fiber.
• Measure and Analyze Optical Fiber Transmission Loss.
• Perform Mach-Zehnder (M-Z) Optical Fiber Interference Experiment.
• Study the Principle of Optical Fiber Temperature Sensing.
• Study the Principle of Optical Fiber Pressure Sensing.

Standard Accessories :

• He-Ne Laser – 1.0–1.5 mW @ 632.8 nm – 1
• Optical Power Meter – Standard – 1
• Beam Splitter – 633 nm – 1
• Temperature Controller – Standard – 1
• Stress Controller – Standard – 1
• Five-Axis Adjustable Stage – Standard – 1
• Beam Expander – Focal Length: 4.5 mm – 1
• Fiber Clip – Standard – 2
• Fiber Support – Standard – 1
• White Screen – With crosshair – 1
• Laser Holder – Standard – 1
• Light Target – Standard – 1
• Power Cord – Standard – 1
• Single-Mode Optical Fiber – 633 nm, 2 m – 1
• Single-Mode Optical Fiber – 1 m, with FC/PC connector on one end – 1
• Multi-Mode Optical Fiber – 633 nm, 2 m – 1
• Fiber Spool – 1 km, 9/125 μm bare fiber – 1
• Fiber Stripper – Standard – 1
• Fiber Scribe – Standard – 1
