Fiber Communication Experiment Kit – Complete Model

This advanced fiber optics experiment system is designed to study the principles of optical fiber communication, transmission, and sensing. It provides a comprehensive platform for performing experiments on optical coupling, transmission loss, interference, beam splitting, optical attenuation, and isolation, making it suitable for advanced laboratory studies in fiber optic communication. Physics Lab Experiments from Atico Exports.

Experiments :

• Study the Fundamental Principles of Optical Fiber Communication.
• Perform Optical Fiber and Light Source Coupling Experiments.
• Measure the Numerical Aperture (NA) of Multimode Optical Fiber.
• Measure and Analyze Optical Fiber Transmission Loss.
• Perform Mach-Zehnder (M-Z) Optical Fiber Interference.
• Study the Principle of Optical Fiber Temperature Sensing.
• Study the Principle of Optical Fiber Pressure Sensing.
• Measure the Parameters of an Optical Fiber Beam Splitter.
• Study the Variable Optical Attenuator and Measure Its Parameters.
• Study the Optical Fiber Isolator and Measure Its Parameters.

Standard Accessories :

• He-Ne Laser – >1.0 mW @ 632.8 nm – 1
• Handheld Light Source – 1310/1550 nm – 1
• Optical Power Meter – Standard – 1
• Handheld Optical Power Meter – 1310/1550 nm – 1
• Fiber Interference Demonstrator – Standard – 1
• Fiber Splitter – 633 nm – 1
• Temperature Controller – Standard – 1
• Stress Controller – Standard – 1
• Five-Axis Adjustable Stage – Standard – 1
• Beam Expander – Focal Length: 4.5 mm – 1
• Fiber Clip – Standard – 2
• Fiber Support – Standard – 1
• White Screen – With crosshairs – 1
• Laser Holder – Standard – 1
• Alignment Aperture – Standard – 1
• Power Cord – Standard – 1
• Single-Mode Beam Splitter – 1310 nm or 1550 nm – 1
• Optical Isolator – 1310 nm or 1550 nm – 1
• Variable Optical Attenuator – Standard – 1
• Single-Mode Optical Fiber – 633 nm, 2 m – 1
• Single-Mode Optical Fiber – 633 nm, 1 m, with FC/PC connector on one end – 1
• Multi-Mode Optical Fiber – 633 nm, 2 m – 1
• Fiber Spool – 1 km, 9/125 μm bare fiber – 1
• Fiber Patch Cords – 1 m × 4, 3 m × 1 – 5
• Fiber Stripper – Standard – 1
• Fiber Scribe – Standard – 1
• Mating Sleeves – Standard – 5
