Fiber Communication Experiment Kit – Enhanced Model

This comprehensive fiber optics communication experiment system is designed to study the principles of optical fiber transmission, optical communication, and fiber optic devices. It enables students to perform experiments on optical coupling, fiber sensing, beam splitting, optical switching, wavelength division multiplexing (WDM), erbium-doped fiber amplification (EDFA), and free-space optical communication. The system provides a complete platform for advanced laboratory training in fiber optic technology. Manufactured by Atico Export India.

Experiments :

• Study the Fundamentals of Fiber Optics.
• Perform Optical Fiber Coupling.
• Measure the Numerical Aperture (NA) of a Multimode Optical Fiber.
• Measure Optical Fiber Transmission Loss.
• Perform Mach-Zehnder (M-Z) Optical Fiber Interference.
• Study the Principle of Optical Fiber Temperature Sensing.
• Study the Principle of Optical Fiber Pressure Sensing.
• Study Optical Fiber Beam Splitting.
• Study the Variable Optical Attenuator (VOA).
• Study the Optical Fiber Isolator.
• Perform Fiber-Based Optical Switching.
• Study the Principle of Wavelength Division Multiplexing (WDM).
• Study the Principle of an Erbium-Doped Fiber Amplifier (EDFA).
• Transmit an Analog Audio Signal Through Free Space.

Standard Accessories :

• He-Ne Laser – 1.0–1.5 mW @ 632.8 nm – 1
• Semiconductor Laser – 650 nm with modulation port – 1
• Dual-Wavelength Handheld Light Source – 1310 nm / 1550 nm – 2
• Optical Power Meter – Standard – 1
• Handheld Optical Power Meter – 1310 nm / 1550 nm – 1
• Fiber Interference Demonstrator – 633 nm beam splitter – 1
• DC Regulated Power Supply – Standard – 1
• Demodulator – Standard – 1
• IR Receiver – FC/PC connector – 1
• Erbium-Doped Fiber Amplifier Module – Standard – 1
• Single-Mode Optical Fiber – 633 nm, 2 m – 1
• Single-Mode Optical Fiber – 633 nm, 1 m, with FC/PC connector on one end – 1
• Multi-Mode Optical Fiber – 633 nm, 2 m – 1
• Fiber Patch Cords – 1 m × 4, 3 m × 1 (FC/PC connectors) – 5
• Fiber Spool – 1 km, 9/125 μm bare fiber – 1
• Single-Mode Beam Splitter – 1310 nm or 1550 nm – 1
• Optical Isolator – 1550 nm – 1
• Optical Isolator – 1310 nm – 1
• Wavelength Division Multiplexer (WDM) – 1310/1550 nm – 2
• Mechanical Optical Switch – 1 × 2 – 1
• Variable Optical Attenuator – Standard – 1
• Fiber Scribe – Standard – 1
• Fiber Stripper – Standard – 1
• Mating Sleeves – Standard – 5
• Radio* – Standard – 1
• Speaker* – Standard – 1

Note :

• Radio and speaker may not be included depending on shipping conditions.
