Filler Compaction Apparatus is used for the determination of the voids content of dry compacted filler.
Apparatus Components :
The apparatus consists of three parts:
Cylinder having inside diameter 25.4 mm
Plunger freely sliding into the cylinder with maximum lateral play of 0.20 ° 0.05 mm
Four columns and metallic base holding the whole, size 100 ° 150 mm
Additional Requirements :
To perform the test, a measuring device (vernier caliper with 0.01 mm accuracy) and 25 mm diameter filter paper are required and should be ordered separately.
Optional Accessories :
It can be fitted with a Blow Counter Kit, which should be ordered separately.
