Filters Kit

With Filters Kit, the different types of filters can be studied: RC and LC, in "T" type configuration, active filters and also study associations of one and others in order to be able to practice with more complex filters, to obtain other filters with certain desired characteristics (low-pass filter, high-pass, band-pass and eliminated band).

ATENG 11308 — Filters Kit

SPECIFICATIONS

• DC Fixed outputs: + 5 V, ± 12 V, 1 A. Development board.
• DC Variable outputs: ± 12 V, 0.5 A. Power supply connector.
• AC Outputs: 12 V or 24 V. Digital visual display unit.
• Outputs through 2 mm terminals, or connectors Sub-D of Logical source.
  25 pins (2 outputs). Set of potentiometers.
  Voltage LED indicators. Pulse generator and inverters.
  Robust construction. Interrupter.
• Power: 110/220 VAC Clock.
• Frequency: 50/60 Hz.
  DIMENSIONS AND WEIGHTS REQUIRED ELEMENTS (Not included)
• Dimensions: 225 x 205 x 100 mm approx. - ATENG 11245. Power Supply.
• (8.85 x 8.07 x 3.93 inches approx.) - ATENG 11246. Base Unit, with built-in power supply.
• Weight: 2 kg approx.
  (4.4 pounds approx.)
