ATENG 10778 — Fixed and Fluidized Bed Unit
Bench-top unit.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
Diagram in the front panel with distribution of the elements similar to the real one.
- Two transparent cylindrical columns, one for air and one for water. Each column:
- Diameter: 50 mm.
- Height: 550 mm
ATENG 10778 detail
- Bed plates.
- Two sizes of bed material (glass beads) are supplied:
- 170/300 micron.
- 250/420 micron.
The columns can be dismantled in order to remove the particle bed.
Water tank of 10 l capacity.
Water pump.
Compressor.
- Water regulation valve and water flow meter, range: 0.07 – 0.55 l/min.
- Two air regulation valves and two air flow meters, ranges: 3 – 21 l/min and 1 – 7.5 l/min.
Two pressure meters (manometers).
- Electrical panel:
Lamp.
Compressor switch.
Pump switch.
Cables and accessories, for normal operation.
