Flexural Testing Frames

The multipurpose Flexural Testing Frames are designed for minimum deflection at maximum load resulting in very high accuracy. The load frame is a welded steel fabrication carrying the ram fitted to the steel base.

Flexural Frames are designed to accept all accessories required for flexural or compression tests.

Flexural Frames are 100 kN, 200 kN, 300 kN capacity U Type, 200 kN, 500 kN capacity Wide clearance U Type and 300 kN, 500 kN capacity C Type open structure designed to allow easy and practical front loading of the specimen.

The very rigid C type design is ideal either for conventional flexural test or for more sophisticated tests such as deformability and ductility index.

The load frame provides the stability needed for accurate and repeatable test results over the years of operation.

Flexural test assemblies should be ordered separately.

The main characteristics are:

• High stability welded assembly
• High accuracy load measurement with load cells
• Can accept wide range of accessories for mentioned standards
• Can be connected to Compression Machine or Hydraulic Power Pack

Standards Compliance :

• Complied as per EN 1338, 1340, 12390-5, 12390-6, BS 1881, ASTM C78, C293, C496
