Flexure Testing Machine – Hand Operated

Flexure Testing Machines (hand operated) is used for judging the strength and stability of concrete specimens of diversity. Our machine has been developed as per the international standards IS 516, BS 1881, and ASTM C 78. The unit is designed to test the accurate flexural strength of concrete beams. The design provides the utmost rigidity throughout their working range. The load is applied by the top of the machine through the piston fitted on top.

Usage :

• Suitable for laboratory experiment

Construction :

• Solid-Robust Construction

Frame :

• Light Weight, Rugged high strength frame

Load Application :

• Applied by the upward movement of a hydraulic ram

Hydraulic Jack :

• Upward & Downward Movement (for testing different size beams)

Pressure / Load Gauge :

• Range : 0-100 kN x 0.5 kN (0-10,000 kgf x 50 kgf)
• Calibrated against NPL/ NCCBM certified proving ring

Spacer :

• Provided for testing specimens of different sizes of beams
• (100 x 100 x 500 mm and 150 x 150 x 700 mm)

Standard Compliance :

• IS 516, BS 1881 and ASTM C 78
