+91 98967 93832This unit has been produced to provide students with a clear visual demonstration of what is happening inside the vapour generating tubes of practical plants. It is possible to see all the processes and types of flow involved during an actual (not simulated) evaporation process, from sub-cooled liquid to superheated vapour. The system operates on a solvent at below atmospheric pressure. Learn about FLOW BOILING DEMONSTRATION UNIT heat-transfer India for optimal educational outcomes.. Liquid is fed by a fine control valve to the lower end of the vertical generating tube, which is the core tube of a concentric tube heat exchanger constructed from glass. Heat transferred from hot water flowing through the jacket of the heat exchanger causes the compound to boil. Learn about FLOW BOILING DEMONSTRATION UNIT price for optimal educational outcomes.. The vapour formed enters a thick walled glass chamber where a water cooled coil causes it to condense, and the liquid formed is returned to the generating tube via the control valve. Hot water for the jacket is provided by a 500W heating element in a second glass walled chamber, with vigorous circulation ensured by a glandless centrifugal pump. Learn about FLOW BOILING DEMONSTRATION UNIT equipment for optimal educational outcomes.. A water driven air ejector is used as required to extract air from the condenser. The unit is floor mounted but occupies only 0. Learn about FLOW BOILING DEMONSTRATION UNIT exporters for optimal educational outcomes.. 25m² floor area.
