FLOW MEASUREMENT METHODS

A Venturi meter, an orifice plate meter and a rotameter that demonstrates typical methods of measuring the flow of an incompressible fluid and shows applications of Bernoulli's equation.

The Flow Measurement apparatus shows the typical methods of measuring the flow of an essentially incompressible fluid (water). It also shows applications of Bernoulli's equation. Students measure flow using a Venturi meter, an orifice plate meter and a rotameter. Learn about FLOW MEASUREMENT METHODS equipment for optimal educational outcomes.. Bernoulli's equation works for each meter. Students find and compare the head losses for each meter. Learn about FLOW MEASUREMENT METHODS specifications for optimal educational outcomes.. They also find the losses in a rapid enlargement and a 90-degree elbow.
