+91 98967 93832This unit has been designed to provide visual and quantitative results related to the flow of air through both a packed and fluidised bed of granular material contained in a vertical glass cylinder. At the lower end is a distribution chamber and air distributor which supports the bed when defluidised. Probes for temperature and pressure measurement, and a horizontal cylindrical heater, can all be moved vertically to any level in the bed chamber. Learn about FLUIDISATION and FLUID BED HEAT TRANSFER UNIT for educational labs for optimal educational outcomes.. Air from a local compressed air supply is delivered through a filter/pressure regulator, an air flow meter fitted with a control valve and an orifice plate (to measure higher flow rates), to the distribution chamber. The heat transfer rate from the heater is adjusted by a manual electronic control and digitally displayed. Learn about FLUIDISATION and FLUID BED HEAT TRANSFER UNIT heat-transfer India for optimal educational outcomes.. Two thermocouples are embedded in the surface of the element – one indicates the surface temperature, and the other, in conjunction with a controller, prevents the heater surface temperature exceeding a set value (up to 200°C). Four grades of Fused Alumina (Aluminium Oxide) Loose Grain are supplied and are suitable for a wide range of fluidisation and heat transfer experiments. Learn about FLUIDISATION and FLUID BED HEAT TRANSFER UNIT suppliers for optimal educational outcomes.. The bed material may be changed quickly, allowing the unit to be back in operation within two or three minutes.
