Foam Cement Stability Tube Cement Density Testing by ATICO EXPORT

The foam cement stability tube is designed to cure foam cement samples at elevated temperatures while isolating the slurry from external pressure. The sealed mold prevents contamination from the pressure medium and maintains foam cement density by preventing the escape of air bubbles from the slurry. A brass tube insert creates a cylindrical cement plug suitable for sedimentation, permeability and other tests. The tapered cell body interior and tube insert allow easy removal. The assembly can also be used with standard cement slurries.

Maximum pressure :

• 3,000 psi (20.7 MPa)

Maximum temperature :

• 400°F (204.4°C)

Size :

• 10" tall × 2.75" diameter (25 × 7 cm)

Weight :

• 13.5 lb (6.3 kg)

Components :

• Cell body
• Tube insert, brass, set of two halves
• Cell cap
• O-ring
• Handle

• Prevents contamination from the pressure medium
• Maintains designed density by preventing release of air bubbles and volume expansion during curing
• Creates cylindrical cement plugs of uniform diameter
• Isolates slurry from external pressure
• Tapered cell body and tube insert for easy removal
• Compatible with foam cement and standard slurries
