Forces in reciprocating engines

Every reciprocating engine generates mass forces. The mass forces of the oscillating masses cannot be compensated completely, while the mass forces of the rotating masses are fully compensated. By using several cylinders it is possible that the forces compensate each other. Learn about Forces in reciprocating engines manufacturers for optimal educational outcomes.. However, disturbing moments may still occur.

• investigation of oscillating and rotating mass forces and moments of a reciprocating engine with up to 4 cylinders
• simulation of single, 2- or 4-cylinder engines
• electronically commutated and speed-controlled drive motor with digital speed display
• continuous adjustment of the angle between cranks
• force sensors to measure forces and moments
• vibration isolation using rubber elements and suitable tuning
• software for data acquisition via USB under Windows 11
