Four-Bar Mechanism Deluxe

The Four-Bar Mechanism, is a bench-top unit to perform laboratory experiments.

ATENG 12064 — Four-Bar Mechanism

Bench-top unit.

Anodized aluminum frame and panels made of painted steel.

Main metallic elements made of stainless steel.

• The “ATENG 12064” unit mainly consists of:
  Four-bar mechanism.
  The bars, made of anodized aluminum, can be connected at different lengths using easy to fit knurled
  bolts.
  Two graduated discs mounted on ball bearings.
  The discs include a scale to measure the input and output angles accurately with the aid of a
  methacrylate indicator. ATENG 12064 detail
