Fourier Transform Infrared Spectrometer for Spectral Physics Instruments

The Fourier Transform Infrared Spectrometer for Spectral Physics Instruments is a high-performance single-beam infrared analysis system designed for rapid spectral acquisition and accurate analytical measurements. Controlled through a computer interface with user-friendly software, the instrument is suitable for applications in chemistry, pharmaceuticals, food and beverage analysis, materials science, environmental testing, quality control, and research laboratories. The spectrometer utilizes a highly stable optical system engineered for long-term reliability and minimal maintenance. Precision mechanical components ensure excellent scanning repeatability, while advanced interferometer technology delivers accurate and consistent spectral results. Its spacious sample compartment accommodates a variety of sampling accessories, enabling analysis of solids, liquids, gases, powders, films, and other sample forms. Combined with powerful software tools for spectral processing and analysis, the system provides a complete solution for infrared spectroscopy applications. Manufactured by Atico Export India.

Wavenumber Range:

• 7800 – 375 cm⁻¹

Resolution:

• 1 cm⁻¹

Signal-to-Noise Ratio:

• 30000:1
• Resolution: 4 cm⁻¹
• 1-Minute Scan at 2100 cm⁻¹

Detector:

• High-Performance DLATGS

Beam Splitter:

• Coated KBr

Light Source:

• Long-Life Stable Infrared Emitter

Electronic System:

• 24-Bit A/D Converter at 500 kHz
• USB 2.0

Power Supply:

• 110 – 220 V AC
• 50/60 Hz

Dimensions:

• 450 mm × 350 mm × 210 mm

Weight:

• 14 kg

Software Functions:

File Management:

• Open Files
• Save Files
• Print Files
• Copy Data
• Paste Data
• Delete Files
• Customizable Settings for Data Collection, Display, Processing, Storage, and Printing

Data Collection:

• Configure Resolution, Scan Range, and Averaging Parameters
• Real-Time Spectral Display
• Instrument Status Monitoring
• Instrument Diagnostics

Spectral Processing:

• Spectral Conversions
• Smoothing Functions
• Normalization Functions
• Spectral Addition
• Spectral Subtraction
• Spectral Multiplication
• Baseline Correction Tools
• Spectral Correction Tools

Analysis Functions:

• Peak Detection
• Peak Labeling
• Spectral Comparison
• Library Search
• Library Management
• Result Display
• Interpretation Tools

Spectral Libraries:

• Application-dependent libraries can be added separately according to analytical requirements

Sample Compatibility:

Liquid Samples:

• Supported

Gas Samples:

• Supported

Solid Pellets:

• Supported

Cuvettes:

• Supported

ATR-Based Measurements:

• Supported

Sample Compartment:

• Accommodates a wide range of sampling accessories and experimental configurations

Parts List:

FTIR Spectrometer:

• Quantity: 1

AC Power Adapter Set:

• Quantity: 1 Set

Polystyrene Film and Replacement Desiccant:

• Quantity: 1 Set

Screwdriver and Allen Wrench Set:

• Quantity: 1 Set

USB Cable:

• Quantity: 1

Software Package:

• Quantity: 1

User Manual:

• Quantity: 1

Software Manual:

• Quantity: 1

• Stable optical bench requiring minimal alignment and maintenance
• Precision mechanics for highly repeatable measurements
• Corner cube optical design for simplified operation and enhanced stability
• Dynamic collimation and movable mirror systems for optimized interferometer performance
• Voice-coil drive mechanism for reliable operation under demanding conditions
• Integrated moisture protection system to safeguard sensitive optical components
• Advanced Electronic System
• Intelligent Humidity Warning Function
• Powerful Analysis Software
• Spacious Sample Compartment
• High Stability Optical Design
• Fast Scanning Speed and High Accuracy
• Suitable for Research, Education, and Quality Control Applications
