Friction Coefficient Measurement Device Lab Experiment

This apparatus is designed for the study and measurement of static and dynamic friction. It enables accurate determination of friction coefficients, comparison of different material pairs, and analysis of the effect of speed on frictional behavior. The system supports both standalone operation and computer-based data acquisition for friction curve analysis. Manufactured by Atico Export India.

Digital Display :

• Four-digit digital display

Peak Value Hold Function :

• Provided

Computer Connectivity :

• For data acquisition and friction curve plotting

Test Speed Range :

• 0 to 30 mm/s

Speed :

• Continuously adjustable

Travel Distance :

• 200 mm

Dimensions and Mass :

• Conform to standard testing requirements

Measuring Range :

• 0 to 10 N

Resolution :

• 0.01 N

Test Materials :

• Supplied with different test materials
• User-defined test specimens can also be used

Data Acquisition :

• Supports computer-based experiments and analysis
• Can also be operated independently without a computer

• Real-time friction measurement and curve generation.
• Suitable for comparative studies of frictional properties under varying conditions.
