Gear Drive Trainer

Comprehensive mechanical training system combines features of multiple training series into one hands on workstation
Allows students to progress through a full range of mechanical skills using a single training system
Versatile assembly for hands on training in gear identification, installation, alignment and troubleshooting
Includes a wide selection of industrial quality gears, shafts and bearings for multiple configurations
Welded aluminum and CNC machined gearbox allows mounting and shimming of tapered roller bearings with different housing types
Suitable for classroom and training labs to improve maintenance skills and understanding of precision gearing

Experiments :
Gear Drives 1 :

• Introduction to gear drives
• Spur gear installation, alignment and backlash adjustment
• Speed and gear ratios
• Introduction to gear trains
• Introduction to compound gear trains

Gear Drives 2 :

• Helical gears
• Worm gears
• Bevel gears
• Miter gears
• Gearboxes
• Repair and maintenance

• 7 gauge formed steel baseplate with provision for tabletop mounting
• Welded aluminum gearbox for installation of gear sets
• Seven custom bearing housings for installation and shimming of tapered roller bearings
• Two additional flanged bearing units for open gearing applications
• Gear sets include spur gears, helical gears, worm and worm gear, and bevel or miter gears
• Includes different pitches, ratios, pressure angles and pitch diameters
• Steel bracket for mounting dial indicator for backlash measurement
• Bearings include tapered roller bearings and radial ball bearings
• Shafting with keyways and keys
• Handle for illustrating thrust and wear patterns
• High durability powder coated surfaces
• Suitable packaging for transport
