GEARBOX APPARATUS

A sliding mesh gearbox with clearly visible gears, aiding student understanding of mechanical principles involved in gear selection and power transmission. Represents a typical 3 forward ratio and reverse sliding mesh arrangement. Input and output shafts can be reversed. Learn about GEARBOX APPARATUS for educational labs for optimal educational outcomes..

• Gear arrangement: 2 × 52T, 2 × 39T, 2 × 26T, 2 × 20T gears
• Enables velocity and torque ratios to be determined
• Transparent protective cover for safe viewing during operation
• Suitable for frame or wall mounting
• Load hangers: 2 × 100 g each
• Weights set: 1 × 5 N, 4 × 2 N, 4 × 1 N, 5 × 0.2 N, 4 × 0.1 N
