GEARED SYSTEMS

An experimental unit to allow students to find the dynamic efficiency of various drive types. The unit comes complete with a gear drive unit which can be configured as a simple or compound drive.

A bench-mounting base unit forms the main part of this set of products. Supplied with a three-shaft gear drive unit as standard, the base unit dynamically tests the gear drive and the other optional drive units including Toothed Belt Drive, Round Belt Drive, Roller Chain Gear Drive and Helical Gear Drive. The dynamic tests run the input of the different drive units at a given speed using a motor, while measuring the input power. Learn about GEARED SYSTEMS manufacturers for optimal educational outcomes.. At the same time, a dynamometer loads the output of the drive unit while measuring the output power. Students use the measurements to find the performance and efficiency of the drive unit. Learn about GEARED SYSTEMS theory-of-machines India for optimal educational outcomes.. Students may set the gear unit (supplied) as a simple or compound drive by sliding a gear in or out of mesh on the third shaft.
