Geometrical Optics Experiment Kit

Experiments :

• Measurement of the focal length of a convex lens using the autocollimation method.

Experiments :

• Measurement of the focal length of a convex lens using Bessel’s method.

Experiments :

• Determination of the focal length of a convex lens using the lens formula.

Experiments :

• Measurement of the focal length of a concave lens.

Experiments :

• Measurement of the focal length of an eyepiece.

Experiments :

• Determination of nodal points and focal length of a lens combination.

Experiments :

• Measurement of microscope magnification.

Experiments :

• Measurement of telescope magnification.

Experiments :

• Assembly and operation of a slide projector.

Optical Rail :

• Length: 1 m.
• Material: Aluminum.

Optical Carriers :

• General Carriers: 2 Nos.
• X-Translation Carriers: 2 Nos.
• X-Z Translation Carrier: 1 No.

Two-Axis Mirror Holder :

• 1 No.

Lens Holders :

• 2 Nos.

Adaptor Piece :

• 1 No.

Lens Group Holder :

• 1 No.

Eyepiece Holder :

• 1 No.

Plate Holder :

• 1 No.

White Screen :

• 1 No.

Object Screen :

• 1 No.

Standing Ruler :

• 1 No.

Biprism Holder :

• 1 No.

Magnetic Base With Holder :

• 1 No.

Direct Reading Microscope :

• 1 No.

Reticle :

• Scale Division: 1/10 mm.

Millimeter Scale :

• Length: 30 mm.

Optical Lenses :

• Focal Lengths: 45 mm, 50 mm, 100 mm, -60 mm, 150 mm, and 190 mm.
• One each supplied.

Plane Mirror :

• Dimensions: Ø36 mm × 4 mm.

45° Glass Holder :

• 1 No.

Eyepiece :

• Doublet Lens Design.
• Focal Length: 34 mm.

Slide Projection Plate :

• 1 No.

Variable Bromine-Tungsten Lamp :

• Rating: 12 V / 30 W.

Small Illumination Lamp :

• 1 No.

Designed For :

• Physics Lab Experiments from Atico Exports.
