Geometrical Optics Experimental Set Physics Science Kits

Experiments:

Colours:

• Coloured light and coloured objects
• Mixture of colours

Shadows:

• Casting shadows
• Coloured shadows

Reflection:

• Reflection from a plane mirror
• Reflected images, image reversal
• Multiple reflections from a mirror
• Reflection from a concave mirror (focal point and spherical aberration)
• Reflection from a parabolic mirror
• Reflection from a convex mirror

Refraction:

• Determining refractive index with a semi-circular object
• Determining refractive index with a parallel block
• Angle of minimum deflection for a prism
• Total internal reflection in a semi-circular object
• Total internal reflection in a prism
• Focal point of a converging lens
• Focal point of a diverging lens
• Spherical aberration

Product Information:

• Equipment set for the execution of bench-based optical experiments
• Consists of a light box in a sturdy plastic housing and numerous optical components
• The complete set is housed in a sturdy styrofoam storage case
• The light box has four light outlets: front, back, and two side outlets with hinged mirrors for experiments on color mixing and shadows
• All openings are equipped with mounts for optical components in 50 × 50 mm slide frames
• Parallel, convergent, and divergent light can be generated by adjusting a mixer lens at the front of the lamp
• Includes two double-sided slit diaphragms for creating four different beam configurations
• Power supply not included

Contents:

• Light box
• Plane mirror (glass)
• Concave mirror (metal)
• Convex mirror (metal)
• Bi-convex lens, large (transparent acrylic)
• Bi-convex lens, small (transparent acrylic)
• Bi-concave lens (transparent acrylic)
• Parallel plate (transparent acrylic)
• Semi-circular object (transparent acrylic)
• 60° prism (transparent acrylic)
• Asymmetrical 90° prism (transparent acrylic)
• Symmetrical 90° prism (transparent acrylic)
• Slit diaphragms
• Color filters (in slide frame)
• Color charts
• Pair of connector leads with 4-mm plugs

Lamp :

• 12 V, 36 W

Connections :

• 4-mm socket

Light box: approx. :

• 17.5 × 10.0 × 6.5 cm

Storage case: approx. :

• 25 × 24 × 10 cm
