The trainer is built around a special work bench that incorporates a functioning Geothermal Heat Pump System which can be used to study the added efficiency of heat pump systems by utilizing geothermal principles to enhance their functions.
A geothermal circuit is embedded into the heat pump system and the unit can be operated in various configurations.
The refrigeration circuit is displayed on a colorful printed diagram. Refrigeration lines are color-coded to indicate the state of the refrigerant.
Control panel with instrumentation including Line Voltage, Ampere (Total Current) and temperature meter with digital display are provided as standard to control the trainer and to facilitate measurements.
Geothermal heat pump capacity: 4.5 kW.
The unit comes with experiment manual containing theory, standard operating procedures, experiment procedures and references.
