Half Shade Polarimeter Without Accessories for Physics Lab Experiments

Half Shade Polarimeter is a useful apparatus designed for understanding, studying, and analyzing the concept of polarization. For accurate determination of specific rotation, the instrument works by comparing the brightness of two halves in the field of view.

The apparatus is based on Biot’s Law. When plane-polarized light passes through an optically active substance, the plane of polarization rotates. By comparing the brightness of the two halves, the optical rotation produced by an optically active substance in solution form can be determined.

Physics Lab Experiments Setup from Atico Exports.

Objective :

• Determination of the Specific Rotation of Sugar Solution Using Half Shade Polarimeter
• Study of Variation of Angle of Rotation of Sugar Solution with its Concentration
• Study of Optical Rotary Dispersion of Sugar Solution
• Determination of the Dependence of Angle of Rotation of Sugar Solution on the Wavelength of Light (Optional)

Polaroid :

• Thickness: 0.1 mm
• Diameter: 26 mm
• Type: Nitrocellulose Polymer

Half Wave Plate :

• Wavelength: 589 nm
• Type: Quartz

Objective Lens :

• Type: Double Convex
• Focal Length: 50 mm

Eyepiece :

• Type: Double Convex
• Focal Length: 200 mm

Polarimeter Tube :

• Length: 100 mm (1 dm)
• Material: Borosilicate Glass
• Volume: 23 ml

Sodium Vapour Lamp :

• Wavelength: 5893 Å
• Power: 35 W

• Sodium Vapour Lamp Light Source
• Adjustable Height
• Circular Scale Graduated from 0° to 360°
• Borosilicate Glass Polarimeter Tube with Bubble Trapper in the Middle
