Hall Effect Experiment Complete Set Up

The Hall Effect Experiment is designed to study the Hall Effect in semiconductor materials and determine the Hall coefficient, carrier concentration, and carrier mobility. The experiment helps distinguish between different types of charge carriers, which cannot be determined through resistivity measurements alone. It provides a comprehensive setup for understanding the electrical properties of semiconductor materials and their behavior in the presence of a magnetic field. Manufactured by Atico Export India.

Principle

When an electric current flows through a conductor or semiconductor placed in a magnetic field perpendicular to the direction of current, a voltage is developed across the specimen in a direction perpendicular to both the current and the magnetic field. This voltage is known as the Hall Voltage, and the phenomenon is called the Hall Effect.

In this experiment, the semiconductor crystal mounted on a PCB is positioned between the pole pieces of an electromagnet. A constant current is supplied through the crystal, while the electromagnet generates a controlled magnetic field. The magnetic field strength is measured using a digital gauss meter with a Hall probe, and the resulting Hall voltage is measured using a digital multimeter.

Objectives

• Study the Hall Effect in semiconductor materials.
• Determine the Hall coefficient of a semiconductor.
• Identify the type of charge carriers present in the semiconductor.
• Measure carrier concentration.
• Determine carrier mobility in conjunction with resistivity measurements.
• Analyze the relationship between magnetic field, current, and Hall voltage.

System Components

Hall Probe :

• For measuring magnetic field.

Advanced Power Supply :

• Provides regulated power for the experiment.

Electromagnet Setup :

• Generates the required magnetic field.

Constant Current Power Supply :

• Supplies constant current to the semiconductor sample.

Digital Gauss Meter :

• Measures magnetic field intensity.

3½ Digit Multimeter :

• Measures the Hall voltage accurately.

Hall Effect Experiment Kit :

• Complete experimental setup.

Complete Experimental Setup :

• Provides all essential components required for Hall Effect measurements.

Constant Current Source :

• Supplies stable current through the semiconductor sample.

Electromagnet :

• Generates a uniform magnetic field for accurate experimentation.

Digital Measurement System :

• Measures Hall voltage and magnetic field with high accuracy.

Semiconductor Sample Mounting :

• Crystal mounted on PCB for convenient positioning between electromagnet pole pieces.
