Hammer Crusher

The Hammer Crusher is a high-performance machine designed for the rapid, safe, and efficient size reduction of medium-hard, hard, and brittle materials. It serves as an ideal solution for pilot scale studies in laboratory settings.
High moisture content in materials can make crushing challenging with conventional crushers. However, the Hammer Crusher excels in this area, effectively handling and crushing wet and high-moisture materials with ease. Its specialized design ensures reliable performance, making it an ideal choice for applications involving materials such as coal.
Crushing Chamber Dimensions: ° 300 x 190 mm

Working Principle :

• The Hammer Crusher is a machine designed for the rapid and efficient crushing of materials. During operation, the loaded material is fragmented by the cyclical movement of the hammers. When activated, the hammers rotate with the power of the motor, delivering high-speed impacts onto the material. This impact effect leads to the crushing and size reduction of the material.
• The crushed material then reaches the built-in screening system. The screen has holes of specific sizes and is used to adjust the size of the material. Crushed particles pass through the screen, allowing for separation and collection based on the desired size. This system is particularly designed for processing challenging materials, such as coal with high moisture content, and offers high efficiency along with energy savings.

Fields of Application :

• Mining, Metallurgy, Recycling and Waste Recovery, Geology, Chemistry, Plastics and Polymers, Iron and Steel, Energy, Biotechnology, Environmental Management, Construction and Building, Agriculture, Glass and Ceramics

Application :

• Fine Crushing

Capacity :

• 2500 kg/h

Feeding Size :

• < 100 mm

Final Fineness :

• < 1 mm

Power and Electricity :

• 4 kW, 380 V, 3p, 50 Hz

Voltage Compatibility :

• Compatible with various voltages

Dimensions :

• 700 ° 1500 ° 1600 mm

Weight :

• 650 kg

Equipment & Accessories :

• Interchangeable Screens: With its interchangeable screens, the Hammer Crusher allows for the production of end products in various sizes.

• Screens with 5mm, 8mm, and 12mm mesh openings for use in the crushing chamber of the Hammer Crusher:

Best Crusher for Clay, Limestone, Coal, and Other Challenging Materials :

Hammer Crusher :

• High-moisture and cohesive materials can cause clogging, sticking, and inefficiency in many crushers. However, Hammer Crusher eliminates these issues completely, ensuring smooth and efficient crushing of clay, limestone, coal, marl, gypsum, and similar challenging materials.
  With its specially designed rotor and impact mechanism, the material is crushed efficiently without sticking or clogging. Our hammer crushers provide high efficiency, low maintenance costs, and exceptional durability, making them the best choice for these types of materials.
  If you are looking for the best limestone crusher, clay crusher, coal crusher, or a crusher for high-moisture materials, our hammer crusher is the ideal solution!
• Best crusher for clay, limestone, coal, gypsum, marl, and similar materials
• Designed to prevent clogging and material sticking
• Powerful impact crushing for high efficiency
• Low maintenance, long-lasting performance
