Heat transfer in the tubular heat exchanger

This unit models convective heat transfer in tubular exchangers, often used for viscous media like sewage sludge. It provides even flow distribution and clear operational data for educational analysis.

• parallel or counterflow operation adjustable via ball valves
• closed, insulated hot water circuit with tank and thermostat heater
• midpoint temperature sensors for transfer path analysis
• flow measurement via 2 impeller flow rate sensors
• software for data acquisition via USB under Windows 11
