The Heat Transfer Seriesto study and compare different types of heat transfer on a small scale.
Technical Specifications
ATENG 12811 — Heat Transfer Series
ATENG 12812. Electronic Console (Common for available Units type “TXC/.B”):
Common for the required elements (at least one) (Not included).
Metallic box.
Temperature sensors connections.
Digital display for temperature sensors.
Selector for temperature sensors.
Level switch connection.
Air flow sensor connection.
Digital display for the air flow sensor.
Radiation sensor connection.
Digital display for the thermal radiation.
Switch and regulator for the heating element power (AR-1) (0-100%).
Heating element (AR-2) controller. It is a programmer to fix a setpoint and prevent the heating
element temperature from exceeding that setpoint. The maximum safety temperature can never
be exceeded.
Switch and regulator for the fan flow rate (0-100%).
Pump switch.
Digital display (wattmeter) for the power of the resistance AR-1, it is shown in watts.
Main switch.
Cables and accessories, for normal operation.
