represents a heating control system of a house, which emulates a home heating system with a heating circuit and two radiators.
Technical Specifications
ATENG 12490 — Heating System Control
All “N-EM” modules contains:
Painted Metallic front panel with an ABS plastic case, which can be mounted in vertical position or used on the surface of a table.
Diagram or drawing of the emulated system.
Connector in the front panel that contains all the required signals to work with the emulator.
Different led colors lamps, switches, push buttons, etc. depend on the type of hardware emulator.
Cables and Accessories, for normal operation.
