High Capacity Circulating Water Bath

The Constant Temperature Circulating Water Bath is designed to provide precise and stable temperature control for laboratory applications. It features a built-in pressure suction pump that continuously circulates constant-temperature liquid to external equipment for efficient heat transfer. A microprocessor-controlled system ensures accurate temperature regulation, while the integrated safety alarm protects samples by monitoring temperature deviations and liquid levels. The digital display provides convenient monitoring and user-friendly operation. Laboratory Equipment from Atico Exports.

• Research laboratories
• Enzymatic experiments
• Serological testing
• Industrial laboratories
• Sample temperature control
• External circulation applications
• General laboratory heating applications

Inner Chamber Dimensions :

• 330 × 300 × 150 mm

Temperature Range :

• 5°C to 100°C

Capacity :

• 22.5 L

Pump Flow :

• 4 L/min

Power :

• 2000 W

Temperature Tolerance :

• ±0.1°C

Time Setting :

• 0 to 9999 Minutes

Power Supply :

• 220 V, 50 Hz

External Dimensions :

• 540 × 340 × 340 mm

Weight :

• 11 kg

• Microprocessor-controlled operation
• Built-in pressure suction pump
• Constant temperature liquid circulation
• Environmentally safe refrigeration system
• Audio and visual alarm system
• Digital temperature display
• High temperature accuracy
• Safety protection for low liquid level and temperature deviation
• Stable and reliable performance
