High Energy Ball Mill Emax

The Emax is an entirely new type of ball mill for high energy milling. The unique combination of high friction and impact results in extremely fine particles within the shortest amount of time.

• Faster and finer grinding than any other ball mill
• Speed of 2000 min-1 allow for ultra-fast pulverization of the sample
• Water cooling permits continuous operation without cool down breaks
• Temperature-controlled grinding
• Narrow particle size distribution thanks to special jar design which improves mixing of the sample

FASTER – FINER – COOLER – THE MOST POWERFUL BALL MILL

• Max. speed 2000 rpm
• Up to 5 mm feed size and 0.08 °m final fineness
• Two grinding stations for jars of min. 50 ml and max. 125 ml
• GrindControl to measure temperature and pressure inside the jar.
• Aeriation lids to control the atmosphere inside the jar
• Temperature monitoring and temperature-controlled grinding, water-cooling of jars
• Storable SOPs and cycle programs, 4 different jar materials for dry and wet grinding

Applications :

• nano grinding, size reduction, homogenizing, mechanical alloying, colloidal milling, high energy comminution

Field of application :

• agriculture, biology, chemistry, construction materials, engineering / electronics, environment / recycling, geology / metallurgy, glass / ceramics, medicine / pharmaceuticals

Feed material :

• medium-hard, hard, brittle, fibrous - dry or wet

Size reduction principle :

• impact, friction

Material feed size :

• < 5 mm

Final fineness :

• < 80 nm

Batch size / feed quantity :

• max. 2 x 45 ml

Speed at 50 Hz (60 Hz) :

• 300 - 2000 min-1

Cooling :

• controlled integrated water cooling / option: external chiller

Temperature control :

• yes (min and max temperature may be defined)

No. of grinding stations :

• 2

Type of grinding jars :

• with integrated safety closure devices

Material of grinding tools :

• stainless steel, tungsten carbide, zirconium oxide

Grinding jar sizes :

• 50 ml / 125 ml

Setting of grinding time :

• 00:01:00 to 99:59:59

Interval operation :

• yes, with optional direction reversal

Interval time :

• 00:01:00 to 99:59:59

Pause time :

• 00:01:00 to 99:59:59

Storable :

• SOPs 10

Interface :

• USB / LAN ( RJ45)

Drive :

• 3-phase asynchronous motor with frequency converter

Drive power :

• 2600 W

Electrical supply data :

• 200-240 V, 50/60 Hz

Power connection :

• 1-phase

Protection code :

• IP 30

Power consumption :

• ~ 3100W (VA)

W x H x D closed :

• 625 x 525 x 645 mm

Net weight :

• ~ 120 kg

Standards :

• CE

Patent / Utility patent :

• Inclined Grinding bowls (US 8,042,754 B2)
