High Resistance by Leakage Method Experiment

High Resistance Measurement by Leakage Method Experiment is designed for measuring very high values of resistance. Digital multimeters or LCR meters are generally suitable for measuring resistance values from approximately 1 Ω to 20 MΩ, but they may not provide accurate measurements for extremely high resistance values.

The leakage method provides an accurate method for measuring high resistance using a sensitive ballistic galvanometer with a lamp and scale arrangement and low-value capacitors. The setup is provided with different values of unknown high resistances with rotary selection and different capacitor values.

Physics Lab Experiments Setup from Atico Exports.

Usage / Application :

• Laboratory

Material :

• Plastic

Color :

• Black

Type :

• Electrical

Power Supply :

• AC Mains

Automation Grade :

• Manual

• Complete Experimental Setup with Required Accessories
• Built-in DC Power Supply
• Ballistic Galvanometer with Moving Coil of Large Moment of Inertia
• Flexible Phosphor-Bronze Ribbon Suspension
• Lamp and Scale Arrangement with Adjustable Stand
• Different Values of Unknown High Resistances with Rotary Selection
• Different Values of Capacitors
• Instruction Manual
