High Resistance Using Substitution Method

Measurement of High Resistance Using Substitution Method setup is designed to study and measure high resistance using the substitution method.

Physics Lab Experiments Setup from Atico Exports.

Objective :

• To Study the Measurement of High Resistance Using the Substitution Method

DC Regulated Power Supply :

• Continuously Variable
• Range: 0 to 50 V
• Overload Protected
• Short-Circuit Protected

Galvanometer :

• Mounted on the Front Panel

Resistance Range :

• 100 kΩ to 1 MΩ
• Selectable Through a Band Switch
• Output Connections Provided on Sockets

Potentiometer :

• Mounted on the Front Panel
• Output Connections Provided on Sockets

Unknown Resistances :

• Two Unknown Resistances: X1 and X2
• Mounted on the Front Panel
