Higher Level Optics Physics Student Science Kits

• Set of equipment for carrying out 38 student experiments on optics
• Comes with comprehensive student and instructor experiment manuals and instructions
• In a tough plastic tray containing a foam insert with cut-outs for the equipment and featuring a transparent lid
• The experiments are designed to be compact but still easy to see when set up and carried out on the supplied optical bench or the base plate
• The optical components are attached in non-slip fashion by magnets
• Supplied overlays designate where the components are to be placed
• Includes comprehensive experiment descriptions (student / instructor version)

Experiments:

• Propagation of light, light beams and rays
• Transparency
• Light and shadow
• Umbra and penumbra
• Reflection from a plane mirror
• Concentration of light by a concave mirror
• Reflection and path of light for a concave mirror
• Reflection and path of light for a convex mirror
• Characteristics of the image from a plane mirror
• When light passes from air into glass / Determination of refractive index
• When light passes from glass into air / Determination of refractive index
• Determination of critical angle for total internal reflection (glass to air)
• Ray diagrams for a rectangular glass block, laws
• Ray diagrams for a glass prism
• Total internal reflection inside a prism
• Path of light through a converging lens
• Determination of focal length for a converging lens
• Ray diagrams with parallel ray and ray through centre of lens (converging lens)
• Path of light through a diverging lens
• Determination of focal length for a diverging lens
• Ray diagrams with parallel ray and ray through centre of lens (converging lens)
• Path of light through a system of lenses
• Image properties (converging lens)
• Image magnification and the lens equation
• converging lens
• d_i = 32 | m = -1
• Image aberrations with converging lenses
• Formation of images in the eye
• Short-sightedness
• Long-sightedness
• Astigmatism
• Cameras
• Slide projectors
• Microscopes
• Galileo telescope
• Kepler’s telescope
• Terrestrial telescope
• Separation of light into a spectrum
• Recomposition of spectral colours
• Additive mixing of colours, complementary colours

Contents:

• Optical bench
• Optical lamp, 5 V, 2 W
• Plug-in power supply, 100 – 240 V, 50/60 Hz
• Tea candles
• Plastic container
• Slide holder, magnetic
• F-shaped slide
• Slide with triple and quintuple slits
• Slide with single slit
• Object for use as an image
• Colour filter, red
• Colour filter, blue
• Acrylic block with holder
• Semi-circular body
• Diverging lens, flat model
• Converging lens, flat model
• Right-angled prism
• Rectangular block
• Objects for casting shadows
• Flexible mirror, magnetic
• Projection screen/inclined bench
• Lenses, f = +50 mm
• Lens, f = +100 mm
• Lens, f = +300 mm
• Lens, f = -100 mm
• Set of overlays
• USB-stick with experiment descriptions
