Hologram Recording Under Room Light Experiment

This experiment kit is designed for comprehensive studies in holography and optical recording techniques. It enables students to perform transmissive and reflective holography, image plane holography, and rainbow holography while gaining practical experience in holographic recording, reconstruction, and optical alignment.

Center Wavelength :

• 650 nm

Bandwidth :

• Less than 0.2 nm

Output Power :

• 40 mW

Exposure Time :

• 0.1 to 999.9 s

Operating Modes :

• B-Gate, T-Gate, Timing, and Open

Manual Control :

• Provided

Transmission/Reflection Ratio :

• Continuously Adjustable

Ratios :

• 5:5 and 7:3

Holographic Plates :

• Red Sensitive Photopolymer Plates

Parts Included :

• Semiconductor Laser – 1
• Laser Safety Goggles – 1
• Semiconductor Laser Holder – 1
• Exposure Shutter and Timer – 1
• Fixed Ratio Beam Splitters (5:5 & 7:3) – 1 each
• Photopolymer Holographic Plates – 1 Box (12 Sheets, 90 × 240 mm each)
• Plate Holder – 1
• Tri-Color Safety Lamp – 1
• Lenses – f = 4.5 mm (1), f = 6.2 mm (1), f = 150 mm (2)
• Plane Mirrors – 3
• Universal Magnetic Bases – 10
• Continuously Variable Beam Splitter – 1
• Lens Holders – 2
• Two-Axis Adjustable Holders – 6
• Sample Stage – 1
• Small Object – 1
• Electric Blower – 1
• Ground Glass – 1
• Small White Screen – 1
• Z-Axis Translation Stages on Magnetic Base – 2
• XY Translation Stage on Magnetic Base – 1
• Illuminometer – 1
• Slit Screen – 1

• Modular optical system for advanced holography experiments.
• Supports multiple holographic recording and reconstruction techniques.
• Suitable for undergraduate, postgraduate, and research-level optics laboratories.
• Precision optical components ensure accurate alignment and high-quality holographic results.
