Hologram Recording Under Room Light Optics Educational Kits

The Hologram Recording Under Room Light Kit is designed to enable holographic recording and reconstruction without the need for darkroom conditions. By utilizing photopolymer recording plates with high diffraction efficiency, the system allows users to create and observe high-quality holograms under normal room lighting conditions. The kit provides a practical and accessible approach to learning holography, making it ideal for educational laboratories and optics training. Students can record holograms, develop them quickly, and reconstruct three-dimensional images using white light, helping them gain a deeper understanding of holographic imaging and interference principles. With its flexible optical configuration and comprehensive set of components, the system supports several holography experiments ranging from basic transmissive holograms to advanced rainbow holography techniques. Physics Lab Experiments from Atico Exports.

Experiments :

• Fresnel (Transmissive) Holography
• Reflective Holography
• Image Plane Holography
• Two-Step Rainbow Holography
• One-Step Rainbow Holography

Semiconductor Laser :

• Center Wavelength: 650 nm
• Bandwidth: < 0.2 nm
• Output Power: 40 mW

Laser Safety Goggles :

• Optical Density Approx. 1 (600–700 nm)

Exposure Shutter & Timer :

• Timing Range: 0.1–999.9 s
• Modes: B-Gate, T-Gate, Timing, Open
• Operation: Manual Control

Continuous Ratio Beam Splitter :

• Transmission/Reflection Ratio Continuously Adjustable

Fixed Ratio Beam Splitters :

• 5:5 and 7:3 Ratios

Holographic Plates :

• Red Sensitive Photopolymer Plates

Semiconductor Laser :

• Quantity: 1

Laser Safety Goggles :

• Quantity: 1

Semiconductor Laser Holder :

• Quantity: 1

Exposure Shutter and Timer :

• Quantity: 1

Fixed Ratio Beam Splitters :

• Quantity: 2

Photopolymer Holographic Plates :

• 1 Box (12 Sheets, 90 mm × 240 mm Each)

Plate Holders :

• Quantity: 2

Tri-Color Safety Lamp :

• Quantity: 1

Lenses :

• Quantity: 4

Plane Mirrors :

• Quantity: 3

Universal Magnetic Bases :

• Quantity: 10

Continuously Variable Beam Splitter :

• Quantity: 1

Lens Holders :

• Quantity: 2

Two-Axis Adjustable Holders :

• Quantity: 6

Sample Stage :

• Quantity: 1

Demonstration Object :

• Quantity: 1

Electric Blower :

• Quantity: 1

Ground Glass Screen :

• Quantity: 1

Small White Screen :

• Quantity: 1

Z Translation Stages on Magnetic Base :

• Quantity: 2

XY Translation Stage on Magnetic Base :

• Quantity: 1

Illuminometer :

• Quantity: 1

Slit Screen :

• Quantity: 1

Beam Expansion Lens :

• f = 4.5 mm

Beam Expansion Lens :

• f = 6.2 mm

Imaging Lenses :

• f = 150 mm (2 Pieces)

• Room-Light Operation
• White-Light Hologram Reconstruction
• Photopolymer Plates for Fast and Easy Development
• Rainbow Holography Experiments
• 40 mW Semiconductor Laser Light Source
• Digital Display with Manual or Remote-Controlled Shutter Operation
• Detailed Instruction Manual
