Holography Experiment Kit Basic Model for Educational Physics Lab

The Holography Experiment Kit Basic Model for Educational Physics Lab is designed to introduce students and researchers to the principles and applications of holography through practical experimentation. Using the interference of coherent light beams, the system enables the recording and reconstruction of three-dimensional holographic images.
The kit utilizes a semiconductor laser to create both reflective and transmissive holograms on photopolymer plates. A major advantage of the system is its ability to reconstruct reflective holograms under normal white-light illumination, eliminating the need for a darkroom environment.The simple recording and development process allows users to create holograms quickly and efficiently. After recording, the holographic image can be viewed as a clear three-dimensional representation under standard room lighting conditions.Designed for educational laboratories and optics training, the kit provides hands-on experience with holographic imaging, interference phenomena, and optical recording techniques. The detailed instructional manual includes experimental principles, setup procedures, and operating guidelines for effective learning.

Manufactured by Atico Export India.

• Reflective Hologram Recording
• Transmissive Hologram Recording
• White-Light Hologram Reconstruction
• Three-Dimensional Image Visualization
• Holography and Interference Studies
• Optics and Physics Laboratory Training

Semiconductor Laser :

• Center Wavelength: 650 nm
• Linewidth: < 0.2 nm
• Output Power: > 35 mW

Exposure Shutter & Timer :

• Timing Range: 0.1 – 999.9 s
• Modes: B-Gate, T-Gate, Timing, Open
• Operation: Manual Control

Laser Safety Goggles :

• Optical Density Approx. 1 (600–700 nm)

Holographic Plate :

• Red Sensitive Photopolymer

Semiconductor Laser :

• Quantity: 1

Laser Safety Goggles :

• Quantity: 1

Exposure Shutter and Timer :

• Quantity: 1

Universal Base :

• Quantity: 6

Two-Axis Adjustable Holder :

• Quantity: 1

Lens Holder :

• Quantity: 1

Plate Holder A :

• Quantity: 1

Plate Holder B :

• Quantity: 1

Adjustable Holder :

• Quantity: 1

Beam Expander :

• Quantity: 1

Plane Mirror :

• Quantity: 1

Demonstration Object :

• Quantity: 1

Red Sensitive Photopolymer Plates :

• 1 Box (12 Sheets, 90 mm × 240 mm Each)

• Room-Light Operation
• White-Light Reconstruction
• Photopolymer Plates for Fast and Easy Development
• Rainbow Hologram Demonstration
• 35 mW Semiconductor Laser Light Source
• Digital Display with Manual or Remote-Controlled Operation
• Detailed Instructional Manual
