Holography Experiment Kit Complete Model for Educational Physics Lab

The Advanced Holography Experiment Kit is designed to provide comprehensive training in holographic recording, reconstruction, and analysis. This complete educational system expands beyond basic holography experiments by supporting both photopolymer and silver salt recording media, allowing users to explore a wider range of holographic techniques and applications.The kit enables the production of reflective and transmissive holograms, as well as advanced holographic elements such as gratings and lenses. It also supports studies in holographic data storage, interferometry, and image reproduction, making it suitable for higher-level optics education and research laboratories.
Designed for operation in both room-light and darkroom environments, the system provides flexibility for various experimental requirements. The comprehensive instruction manual includes experimental configurations, theoretical principles, setup procedures, and operating guidelines to facilitate effective learning and experimentation.

Manufactured by Atico Export India.

Experiments :

• Fresnel Holographic Photography
• Image Plane Holography
• One-Step Rainbow Holographic Photography
• Two-Step Rainbow Holographic Photography
• Holographic Grating Fabrication
• Holographic Lens Fabrication
• High-Density Holographic Data Storage
• Holographic Interferometry
• Holographic Reproduction

Semiconductor Laser :

• Center Wavelength: 650 nm
• Linewidth: < 0.2 nm
• Output Power: > 35 mW

Exposure Shutter & Timer :

• Timing Range: 0.1 – 999.9 s
• Modes: B-Gate, T-Gate, Timing, Open
• Operation: Manual

Continuous-Ratio Beam Splitter :

• Transmission/Reflection Ratio Continuously Adjustable

Single-Sided Rotary Slit :

• Slit Width: 0–5 mm (Continuously Adjustable)
• Rotation Range: ±5°

Laser Safety Goggles :

• Optical Density Approx. 1 (600–700 nm)

Holographic Plates :

• Photopolymer and Silver Salt Types

Semiconductor Laser :

• Quantity: 1

Laser Safety Goggles :

• Quantity: 1

Exposure Shutter and Timer :

• Quantity: 1

Universal Magnetic Base :

• Quantity: 12

Two-Axis Adjustable Holders :

• Quantity: 6

Lens Holders :

• Quantity: 2

Plate Holders :

• Quantity: 2

Adjustable Holder :

• Quantity: 1

Sample Stage :

• Quantity: 1

Single-Sided Rotary Slit :

• Quantity: 1

Objective Lens :

• Quantity: 1

Beam Expanders :

• Quantity: 2

Lenses :

• Quantity: 2

Plane Mirrors :

• Quantity: 3

Continuous-Ratio Beam Splitter :

• Quantity: 1

Demonstration Object :

• Quantity: 1

Red Sensitive Photopolymer Plates :

• 1 Box (12 Sheets, 90 × 240 mm Each)

Silver Salt Holographic Plates :

• 1 Box (12 Sheets, 90 × 240 mm Each)

Tri-Color Safety Lamp :

• Quantity: 1

Illuminometer :

• Quantity: 1

Information Slide :

• Quantity: 1

Fixed Ratio Beam Splitters :

• Quantity: 2

Air Blower :

• Quantity: 1

Instruction Manual :

• Quantity: 1

• Alternative Recording Media (Photopolymer and Silver Salt)
• Suitable for Room-Light and Darkroom Operation
• 35 mW Semiconductor Laser Light Source
• Portable Illuminometer with High Accuracy
• Continuous-Ratio Beam Splitter for Adjustable Light Distribution
• Digital Display with Manual Operation
• Tri-Color Darkroom Safety Lamp
• Detailed Instruction Manual
