ATENG 12068 — Hooke's Joint Mechanism
Bench-top unit with adjustable legs.
Anodized aluminum frame and panels made of painted steel.
Main metallic elements made of stainless steel.
- The “ATENG 12068” unit mainly consists of:
Two universal couplings (cardan joints).
Intermediate shaft made of stainless steel.
Inlet and outlet shafts made of stainless steel.
Adjustment of the angle of the cardan joint.
Two graduated inlet and outlet discs.
Two graduated discs at the base of both couplings.
Both outer discs are mounted in two rotary elements with a graduated disc to read the ATENG 12068 detail
angle at the input and output.
