Horizontal Autoclave ALB592

Horizontal Autoclave is designed for efficient and high-capacity sterilization with a 500 L chamber capacity. It operates within a temperature range of 40 to 134 °C at a working pressure of 0.22 MPa for safe and consistent sterilization performance. The unit features fully automatic control and an integrated drying function for efficient and convenient operation. Over-temperature and over-pressure protection systems enhance operational safety and reliability. Laboratory Equipment from Atico Exports.

• Sterilization of surgical instruments
• Test cloth items
• Laboratory utensils
• Hospitals
• Operating rooms
• Pharmaceutical factories
• Research laboratories

Capacity :

• 500 L

Temperature Range :

• 40 to 134 °C

Maximum Working Temperature :

• 134 °C

Temperature Uniformity :

• ≤ ±2 °C

Working Pressure :

• 0.22 MPa

Maximum Working Pressure :

• 0.23 MPa

Timer Range :

• 0 to 60 min

Drying Time Range :

• 0 to 60 min

Power Consumption :

• 18 kW

Power Supply :

• AC 380 V / 50 Hz

Interior Dimensions :

• Φ 700 × 1300 mm

Exterior Dimensions :

• 1800 × 900 × 1820 mm

Packaging Dimensions :

• 1850 × 1050 × 2100 mm

Net Weight :

• 470 kg

Gross Weight :

• 580 kg

• Gravity displacement sterilization
• Overcurrent protection
• Audible pressure alarm
• Automatic pressure relief
• Low-water level protection
• Stainless steel chamber
• High temperature uniformity
• Cold air discharge
• Fully automatic control
• Integrated drying function
• Over-temperature protection
• Over-pressure protection
• Safe and reliable sterilization performance
