Horizontal Electrophoresis Unit ALB310

Horizontal electrophoresis unit with a leakproof buffer chamber assembly designed for efficient and reliable gel electrophoresis. The large buffer volume provides excellent cooling performance and maintains stable pH throughout the experiment. An integrated transparent safety lid helps prevent liquid volatilization and electrical leakage. Manufactured by Atico Export India.

• Healthcare laboratories.
• Forensic laboratories.
• Research laboratories.
• Clinical laboratories.
• Microbiology.
• Biochemistry.
• DNA fingerprinting.
• Drug testing.
• Protein analysis.
• Genetic testing.

Gel Tray (W × L) :

• 200 × 200 mm
• 200 × 150 mm
• 200 × 100 mm

Buffer Volume :

• 1800 mL

Comb Thickness :

• 1 mm
• 1.8 mm

Comb Throughput :

• 17 samples
• 22 samples
• 36 samples
• 44 samples

Number of Samples :

• 17 to 264

External Dimensions (L × W × H) :

• 397 × 230 × 83 mm

Package Dimensions (L × W × H) :

• 530 × 390 × 220 mm

Gross Weight :

• 5 kg

Standard Accessories :

• Body tank with electrode : 1
• Gel tray (200 × 200 mm) : 1
• Gel tray (200 × 150 mm) : 1
• Gel tray (200 × 100 mm) : 1
• Gel caster : 1
• 1 mm thickness 17 wells comb : 2
• 1.8 mm thickness 17 wells comb : 2
• 1 mm thickness 22 wells comb : 2
• 1.8 mm thickness 22 wells comb : 2
• 1 mm thickness 36 wells comb : 4
• 1.8 mm thickness 36 wells comb : 2
• 1 mm thickness 44 wells comb : 2
• 1.8 mm thickness 44 wells comb : 2
• Leveling feet : 4

• Dismountable electrodes for easy maintenance.
• Transparent polycarbonate top lid for enhanced safety.
• Automatic power-off when the lid is removed.
• Compatible with BPS-1/BPS-2 power supply for controlling the circuit.
