Horizontal Electrophoresis Unit

Horizontal electrophoresis unit capable of processing 2 to 100 samples while running two gels simultaneously. It supports multiple gel sizes, well configurations, and comb thicknesses for flexible operation. The unit features a 650 mL buffer capacity, fluorescent gel tray markings for accurate sample loading, and a dedicated gel casting base for quick and efficient gel preparation. Manufactured by Atico Export India.

• DNA identification.
• DNA separation.
• DNA preparation.
• Molecular weight measurement.
• Genetic research.
• Molecular biology.
• Forensic analysis.

Gel Size (L × W) :

• 60 × 60 mm
• 60 × 120 mm
• 120 × 60 mm
• 120 × 120 mm

Number of Samples :

• 2 to 100

Buffer Volume :

• 650 mL

Comb Configuration :

• 2 + 3 wells
• 6 + 3 wells
• 8 + 18 wells
• 11 + 25 wells

Comb Thickness :

• 1.0 mm
• 1.5 mm
• 2.0 mm

Dimensions :

• 360 × 200 × 200 mm

Net Weight :

• 1 kg

Gross Weight :

• 1.5 kg

Standard Accessories :

• 25 (11+11) teeth comb (1.0 mm) : 1
• 13 (6+6) teeth comb (1.5 mm) : 1
• 18 (8+8) teeth comb (1.5 mm) : 1
• (3+2) / (3+3) teeth comb (2.0 mm) : 1
• 18 (8+8) teeth comb (1.0 mm) : 1
• 13 (6+6) teeth comb (1.0 mm) : 1
• Gel casting device : 1
• Gel tray (60 × 60 mm) : 2
• Gel tray (60 × 120 mm) : 1
• Gel tray (120 × 60 mm) : 1
• Gel tray (120 × 120 mm) : 1
• Lid : 1

• High-quality polycarbonate construction.
• Transparent top lid.
• Quick gel casting base.
• Automatic safety shut-off.
• Removable electrodes.
