Horizontal Electrophoresis Unit ALB328

Horizontal electrophoresis unit with a high-resolution leakproof buffer chamber designed for reliable electrophoretic procedures. The large buffer volume provides efficient cooling and maintains stable pH during high-voltage gel electrophoresis. It features an integrated transparent safety lid to minimize electrical leakage and sample volatilization, along with durable platinum electrodes and a high-quality gel casting system for precise gel preparation. Manufactured by Atico Export India.

• Molecular biology.
• Forensic science.
• Research laboratories.
• Diagnostic laboratories.
• Microbiology.
• Biochemistry.
• DNA separation.
• RNA separation.
• Protein analysis.
• DNA fingerprinting.
• Drug testing.
• Genetic testing.
• PCR amplification.
• Sample quantification.

Gel Tray (W × L) :

• 130 × 130 mm
• 78 × 100 mm
• 48 × 75 mm

Buffer Volume :

• 600 mL

Number of Samples :

• 3 to 104

Rows of Comb :

• 1 to 4

Comb Thickness :

• 1 mm
• 1.5 mm

Gel Tray Thickness :

• 6 mm

Gel Making Mode :

• Gel casting

Dimensions (L × W × H) :

• 305 × 152 × 80 mm

Weight :

• 1.7 kg

Standard Accessories :

• Body tank with electrode : 1
• Gel tray (130 × 130 mm) : 1
• Gel tray (78 × 100 mm) : 1
• Gel tray (48 × 75 mm) : 2
• Gel casting unit : 1
• 1.0 mm thickness 13 wells comb : 2
• 1.5 mm thickness 13 wells comb : 2
• 1.0 mm thickness 26 wells comb : 4
• 1.5 mm thickness 26 wells comb : 2
• 1.0 mm thickness 10 wells comb : 2
• 1.0 mm thickness 15 wells comb : 2
• 1.5 mm thickness 3 wells comb : 2
• 1.0 mm thickness 5 wells comb : 2
• Level adjustment leg button : 4
• Electrical cable : 1

• Dismountable electrodes for easy maintenance.
• Fluorescent ruler on the tray for sample observation.
• Automatic power-off when the lid is removed.
• Lugs for easy lid removal and transportation.
• High-quality gel casting apparatus to prevent gel leakage.
