Hotplate Stirrer with Timer ALB478

Hotplate Stirrer with Timer is a high-performance laboratory hotplate stirrer designed for precise heating and stirring applications. It is capable of stirring up to 20 L of sample at speeds of up to 1500 rpm and operates within a heating temperature range from room temperature to 550 °C. The unit features a brushless DC motor for powerful stirring, a built-in PID controller for stable heating, and an LCD display for clear parameter settings and real-time monitoring. Laboratory Equipment from Atico Exports.

• Chemical laboratories
• Biological laboratories
• Pharmaceutical laboratories
• Industrial laboratories
• Material testing laboratories
• Educational laboratories
• Precise heating and stirring applications

Heating Capacity :

• 20 L

Heating Temperature Range :

• Room Temperature to 550 °C

Temperature Increment :

• 1 °C

Temperature Control Accuracy :

• ± 1 °C (Below 100 °C)
• ± 1% (Above 100 °C)

Speed Range :

• 0 to 1500 rpm

Stirring Positions :

• 1

Working Temperature Range :

• 5 to 40 °C

Working Humidity :

• 80% RH

External Temperature Sensor :

• PT1000 (Accuracy: ± 0.2 °C)

Work Plate Dimension (W × D) :

• 184 × 184 mm (7 inch)

Work Plate Material :

• Glass Ceramic

Magnetic Bar Length :

• 80 mm

Motor Input Power :

• 18 W

Motor Output Power :

• 10 W

Heating Output :

• 1000 W

Ambient Temperature Range :

• 5 to 40 °C

Ambient Humidity :

• 80% RH

Data Connector :

• RS232

Protection Class :

• IP21

Power Consumption :

• 1050 W

Power Supply :

• 100–120 V / 200–240 V, 50/60 Hz

Dimensions (W × D × H) :

• 215 × 360 × 112 mm

Weight :

• 5.3 kg

• Overheating protection
• Glass ceramic work plate for efficient heat transfer and durability
• External PT1000 temperature sensor
• Built-in PID temperature controller
• Brushless DC motor for reliable stirring
• LCD display for real-time monitoring
• Dual control knobs for easy operation
• Remote PC control and data transmission
• RS232 communication interface
