HTHP Filter Press with Threaded Cells 175 mLCement oil and petroleum testing instruments by ATICO EXPORT

The threaded cap cell design allows testing at higher temperatures and pressures while ensuring operator safety. The modular inner cap system enables multiple filter media to be used with a single cell. All cells are supplied with pressure certification, unique serialization and material certification for complete traceability.

Maximum temperature :

• 500°F (260°C)

Maximum pressure :

• 5,000 PSI (34.5 MPa)

Volume :

• 175 mL

Components :

• Graduated cylinder, 50 mL × 1 mL, glass
• Thermometer with metal dial, 5" stem, dual scale: 50° - 500°F / 0° - 250°C
• Heating jacket, 115 Volt
• Heating jacket, 230 Volt
• Back pressure receiver, 15 mL
• O-ring for test cell, Viton® 75D for tests up to 400°F
• O-ring for valve stem, Viton® 75D for tests up to 400°F
• Test cell for cement
• Filter paper
• Adjustable wrench, 6"
• O-ring for valve stem, Viton® 90D for tests above 400°F
• O-ring for test cell, Viton® 90D for tests above 400°F
• Dual nitrogen manifold

Optional :

• Cell carrying tool
• Pressure relief tool
• Spare parts kit
• Cell stand

• Safety: Cell cap cannot be removed if pressure is trapped inside the cell
• Versatility: Interchangeable cell caps enable testing with filter paper, ceramic disks and cement screens using the same cell body
• Compatible with all existing heating jackets
• Pressure capability: Ability to add a piston allows testing above 3,000 PSI
