HTHP Filter Press with Threaded Cells Cement testing instruments by ATICO EXPORT

The modular HTHP filter press cell is designed with safety, versatility and convenience in mind. The two-piece threaded cap design prevents the cell from being opened while pressurized. Interchangeable caps allow easy reconfiguration for testing with different filter media including filter paper, ceramic disks and cement screens using the same cell body. All cells are supplied with pressure certification, unique serialization and material certification for full traceability.

Maximum temperature :

• 500°F (260°C)

Maximum pressure (cell) :

• 5,000 PSI (34.5 MPa)

Volume :

• 500 mL

Cell Caps :

Inlet :

• Removable cement screen, 325 mesh with 60 mesh backup

Outlet :

• Removable cement screen, 325 mesh with 60 mesh backup

Components :

• Graduated cylinder, 100 mL × 1 mL, glass
• Thermometer with metal dial, 8" stem, dual scale: 50° - 500°F / 0° - 250°C
• Heating jacket, 115 Volt
• Heating jacket, 230 Volt
• O-ring for cell, Viton®
• O-ring for valve stem, Viton®
• Adjustable wrench, 6"
• Back pressure receiver, 100 mL
• HTHP filter press cell with threaded cap, 500 mL, for cement
• Dual nitrogen manifold

Optional :

• Nitrogen cylinder
• Cell carrying tool
• Pressure relief tool
• Cell stand
• Spare parts kit

• Safety: Cell cap cannot be removed if pressure is trapped inside the cell
• Versatility: Interchangeable cell caps enable testing with filter paper, ceramic disks and cement screens using the same cell body
• Compatible with all existing heating jackets
• Pressure capability: Ability to add a piston allows testing above 3,000 PSI
