HTHP Viscometer oil and petroleum testing instruments by ATICO EXPORT

For extremely high temperature and high pressure viscosity measurements, the HTHP viscometer accurately determines the rheological properties of drilling fluids, completion fluids and cement in terms of shear stress, shear rate, time and temperature at pressures up to 30,000 psi (206.9 MPa) and temperatures up to 500°F (260°C).

Using exclusive rheology software, the system is easy to operate for beginners while remaining versatile enough for advanced research and demanding test parameters.

Maximum pressure :

• 30,000 PSI (206.8 MPa)

Maximum temperature :

• 500°F (260°C)

Motor speed :

• 0.01 - 1000 RPM

Shear rate range :

• 0.01 - 1022 sec⁻¹

Viscosity range :

• 0 - 300 cP @ 300 RPM

Requirements :

• Electrical: 115 or 230 Volt, 50/60 Hz
• Air supply: 100 - 150 psi
• Water source: Standard tap water
• Water drain

• Low shear rates as low as 0.01 sec⁻¹
• Real oilfield geometry using traditional oilfield bob and rotor for easy-to-use measurements
• Touchscreen display showing current temperature, pressure, RPM, viscosity and shear stress
• Computer-controlled operation
• Versatile operation on 115 or 230 Volt
• Ergonomic design
