Hydraulic Specimen Extruder - Horizontal, Motorised

STANDARDS COMPLIANCE :

• COMPLIED AS PER EN 13286-2, 13286-7, 12697-30; AASHTO T134, T180, T193; ASTM D698, D1557, D1587, D1559, D1883; BS 598-107, 1377-4, 1924-2

Application :

• The Motorized Hydraulic Extruder is used for quick and smooth extrusion of soil specimens from 38 mm to 160 mm tubes and also Proctor, CBR and Marshall Moulds.

Specifications :

• The Extruder has 60 kN capacity and 70 cm ram travel.
• Specimens with different sizes can be safely collected after extrusion with the help of adjustable V-shaped sample receiving table. This table can easily be dismantled for space saving. The hydraulic piston can be stopped at any position during extraction.

Supplied Complete With :

• Adaptors for ° 100 mm (4–) and ° 150 mm (6–) moulds.

Ordering Information :

• ° 38 mm, ° 50 mm and ° 70 mm Adaptors (ring and tamper) should be ordered separately

Type :

• AECE2084/A - Horizontal
• AECE2084/B - Vertical

Capacity (kN) :

• AECE2084/A - 60
• AECE2084/B - 60

Ram Travel (cm) :

• AECE2084/A - 70
• AECE2084/B - 70

Dimensions (cm) :

• AECE2084/A - 280°50°125
• AECE2084/B - 65°75°175

Weight (kg) :

• AECE2084/A - 200
• AECE2084/B - 200

Power Supply :

• AECE2084/A - 220 V, 50 Hz, 1 ph
• AECE2084/B - 220 V, 50 Hz, 1 ph
